Summary

  • A cross country style hard-tail e-mountain bike with 80mm suspension fork, knobby trail tires, and sturdy alloy pedals, includes a trigger throttle up to 20 MPH
  • Lots of adjustability with the display panel, including speed, the 12-magnet cadence sensor is very responsive, motor inhibitors in both of the levers, large 180mm hydraulic disc rotors in front and rear
  • Upgraded suspension fork, hydraulic brakes vs mechanical, better saddle, derailleur, cassette range, battery, and display from the regular Moscow version
  • The kickstand works decently well but can block the left crank arm when down, 2amp charing is slow for the high capacity battery, some wires stand out vs. being completely internal, not much room to add things on the handlebar

Video Review

Trusted Advertisers

Introduction

Make:

NCM

Model:

Moscow Plus

Price:

$1,899 ($2,399 CAD)

Body Position:

Forward

Suggested Use:

Urban, Trail, Mountain

Electric Bike Class:

Throttle on Demand (Class 2), Speed Pedelec (Class 3)
Learn more about Ebike classes

Warranty:

1 Year Comprehensive

Availability:

United States, Canada, Australia, United Kingdom, Spain, Italy, Germany

Model Year:

2019

Bicycle Details

Total Weight:

56.1 lbs (25.44 kg)

Battery Weight:

9.2 lbs (4.17 kg)

Motor Weight:

10 lbs (4.53 kg)

Frame Material:

6061 Aluminum Alloy

Frame Sizes:

19 in (48.26 cm)20.5 in (52.07 cm)

Geometry Measurements:

Medium: 19" Seat Tube, 22.5" Reach, 28.5" Stand Over Height, 33.5" Minimum Saddle Height, 27.5" Width, 72" Length, Large: 20.5" Seat Tube, 22.5" Reach, 30" Stand Over Height, 35.5" Minimum Saddle Height, 27.5" Width, 74" Length

Frame Types:

High-Step

Frame Colors:

Satin Black with Blue Accents

Frame Fork Details:

SR Suntour XCM30 Spring Suspension, 80mm Travel, Compression Adjust with Lockout, Preload Adjust, 30mm Stanchion Diameter, 100mm Hub Spacing, 9mm Axle with Quick Release Skewer

Frame Rear Details:

135mm Hub Spacing, 12mm Keyed Threaded Axle with 20mm Nuts

Attachment Points:

Fender Bosses, Rear Rack Bosses, Bottle Cage Bosses

Gearing Details:

24 Speed 3x8 Shimano Altus Front and Acera Rear Derailleur, Shimano Cassette 11-32 Tooth

Shifter Details:

Shimano Triggers on Left and Right (One-Way High Lever, Three-Shift Low Lever)

Cranks:

Shimano FC-M311, Forged Aluminum Alloy Arms, 170mm Length, Square Taper Bottom Bracket Spindle, 48-38-28 Tooth Steel Chainrings

Pedals:

Wellgo B087 Aluminum Alloy Platform with Fixed Pins, Black

Headset:

Neco, Integrated, Threadless Internal Cups, Tapered 1-1/8" to 1-1/2"

Stem:

Promax, Alloy, 90mm Length, 31.8mm Clamp Diameter, One 15mm Spacer, Two 10mm Spacers, One 5mm Spacer

Handlebar:

Flat, Aluminum Alloy, 680mm Length

Brake Details:

Tektro HD-E350 Hydraulic Disc with 180mm Rotors, Three-Finger Levers with Motor Inhibitors

Grips:

Velo, Ergonomic Rubber, Locking

Saddle:

Selle Royal, LookIN

Seat Post:

Promax, Aluminum Alloy, Forged Head

Seat Post Length:

350 mm

Seat Post Diameter:

30.9 mm

Rims:

Aluminum Alloy, Double Walled, 25mm Outer Width, 36 Hole, Black

Spokes:

Stainless Steel, 13 Gauge, Silver with Nipples

Tire Brand:

Schwalbe Smart Sam, 27.5" x 2.25" (57-584)

Wheel Sizes:

27.5 in (69.85cm)29 in (73.66cm)

Tire Details:

26 to 54 PSI, 1.8 to 3.7 BAR, Performance, ADDIX Compound

Tube Details:

Schrader Valve

Accessories:

Plastic Flick Bell, Sticker Slap Guard, Steel Derailleur Guard, Center Mount Adjustable Kickstand

Other:

Locking Removable Semi-Integrated Downtube Battery Pack (Reention Cylinder and Key), 9 Mosfet 18 Amp Current Controller, 1.5lb 2 Amp Charger, Sine Wave Controller, Basic Assembly Toolkit, 275.5lb Max Load

Electronic Details

Motor Brand:

Das-Kit X15R

Motor Type:

Rear-Mounted Geared Hub
Learn more about Ebike motors

Motor Nominal Output:

500 watts

Motor Torque:

80 Newton meters

Battery Brand:

Dehawk H12 (Made by DLG)

Battery Voltage:

48 volts

Battery Amp Hours:

16 ah (Optional 13ah Battery)

Battery Watt Hours:

768 wh (Optional 624wh Battery)

Battery Chemistry:

Lithium Nickel Cobalt Manganese (Li-NCM)

Charge Time:

6 hours

Estimated Min Range:

40 miles (64 km)

Estimated Max Range:

95 miles (153 km)

Display Type:

Das-Kit C7, Fixed, Backlit, Monochrome LCD, Buttons: +, Power, Set, -, (Press Power for Backlight, Hold Set for 3 Seconds to Clear Trip Distance, Hold - for Walk Mode, Hold + and - for Settings and Enter Code 8018)

Readouts:

Amperage Power Meter, Assist Level (0-6), Speed, Odometer, Trip Time, Trip Distance 1, Trip Distance 2, BMS Voltage, Battery Capacity (5 Bars)

Display Accessories:

Full Size USB Type A Port on Right Side of Battery (5 Volt, 500 mA)

Drive Mode:

Cadence Sensing Pedal Assist, Trigger Throttle (Sealed 12-Magnet Sensor)

Top Speed:

25 mph (40 kph)(20 MPH Throttle, Adjustable)

Trusted Advertisers



Written Review

To run the forums, host the website, and travel, I charge a universal service fee for my reviews. This review was sponsored by NCM. My goal is to be transparent and unbiased, this video and written review are not meant to be an endorsement of NCM products.

NCM is a new company to me, but they are using reliable and proven systems in their ebikes, so in someway, there is a nice familiarity to it. Today we are checking out their Moscow Plus, the big brother to the Moscow. The Moscow Plus features a nicer suspension fork, hydraulic brakes, more comfortable saddle, and an upgraded derailleur with more gear ranges. There is also a better battery coupled with a nicer display. Because they share the same frame however, you will find a lot of parallel information in this review if you read the write up on the regular Moscow. So the Moscow Plus here is an aluminum alloy frame hard-tail ebike that comes in 2 sizes. Each size also has tire options as well, so basically there is a 19” frame and a 20.5” frame and you can choose either 27.5” tires, or 29” tires. Today we have the 19” frame with the 27.5” Schwalbe Smart Sam knobby tires. Overall the bike weighs about 56.1lbs, (about 1.4lbs lighter than the regular Moscow) and costs $1,899 USD and $2,399 in CAD. As I mentioned before, it is a bit of a hard-tail setup, so you do get this nice SR SunTour XCM30 spring suspension fork. It has 80mm of travel, larger 30mm stanchions, and includes compression adjust, lockout, and preload adjust. Pretty standard hub spacing in the front, 100mm, and there is a 9mm quick release skewer in the front, but none in the back since this is a hub-drive. I am told that it has a maximum weight capacity of 275.5lbs, which is higher than standard. This might come in handy since the bike does have bottle cage bosses, rack bosses, and even fender provisions, so you could really load it up with accessories and it should handle it very well. I like that there is an adjustable length kickstand included, but it is center mounted. That means that you could have the pedals strike the kickstand when down and reversing, an annoying occurrence sometimes referred to as ‘pedal-lock’. The seat post here is a rigid post, which is normal, but since it is 30.9mm, you could swap that out with a nice suspension seat post to get some more cushion on top of that front suspension fork. Other features include ergonomic Velo grips, Wellgo aluminum alloy platform pedals, and one of my favorites, a slap guard that will protect the bike frame and paint from getting nicked by the chain and scratching the paint.

Driving the Moscow Plus is a 500 watt nominally rated planetary geared hub motor. I love that it is fairly compact given the high power output. Power wise, it can deliver up to 80nm of torque, which is quite high, but it cannot leverage gears the way that a mid-drive could. The upside is that the motor always feels zippy, it doesn’t matter which of the gear combinations you are pedaling with. And, the motor can deliver instant power with the minimalist throttle. Hub motors are a great fit for hardtail mount bikes because there is no rear suspension to interfere with. As you shift gears, there won’t be increased mashing or forces applied to the drivetrain because the motor operates completely independently of the chain and sprockets. Moving the bike is done here with either the throttle or the cadence based pedal assist. Of course, this motor will use more power if you’re constantly starting with the throttle, but that’s a worthwhile trade for someone like myself, who has a knee injury. I love being able to override assist with the throttle at any time. I also love that the throttle is easily disabled by removing a cable in case you need to make the bike legal for other trails or local laws. Mechanically, you have 3 rings in the front (48,28, and 28), but sadly, there is no chain cover to protect your clothing. In the rear you have an upgraded 11-32 tooth setup, so a bit better range than the standard Moscow. All in all, it is a Shimano Acera system, and you also get 8 speeds, trigger shifters, and a couple of display windows that tells you what gear you are in. There is a derailleur guard here too, something I love since it protects the derailleur during shipping, or if the bike takes a spill some day. Stopping the Moscow Plus is a set of hydraulic brakes. This was one of my grips on the regular Moscow, so I am happy to see they are offered here in a set of 180mm rotors for both the front and rear. Another upgrade here on the Plus is motor inhibitors in both brake lines. The regular Moscow only had it on one lever so I am glad it is here as it helps cut power to the motor when stopping.

Powering the NCM Moscow Plus is a high capacity Lithium-ion battery pack, offering 48v 16ah hours of capacity! I would say that’s a nice upgrade from the 48v 13ah of the regular Moscow…that means you can go further or ride at higher speeds. I love that they use a sealed external controller, this allows a lower cost for replacement batteries, and keeps the controller protected from harsh elements. Where as some companies are $800-$1000 range for a new battery, this keeps the NCM battery cost to around $500. Note that whenever you’re operating around or above 20 mph, air resistance is going to cause exponential energy draw and range will be decreased. This pack delivers electricity to the motor, but also the backlit display panel (hold the + icon to turn on backlighting), and even a full sized USB charging port on the top right side. You could use this port to maintain phones, GPS, or music devices as you ride or when parked at home or a camp site. My friends recently took a bikepacking trip using another electric bike, and this sort of charging-on-the-go feature would be really handy. If you’re excited to charge while riding, I recommend using a right-angle USB adapter like this, just to keep the wires tucked in and out of the way while you pedal. The battery pack weighs more than average at 9.2lbs, but the alloy casing is sturdy and most of the weight is kept low and center on the bike frame. I took the pack off when moving the bike to our review location, to reduce load on my car rack. If you live up stairs, removing the battery is a great idea, and for those who need to leave the bike in a cold, hot, or wet locations… being able to protect and charge the battery inside is a great thing. It’s best to maintain the pack above 20% and avoid extreme temperatures. It’s going to take a bit longer to fill this battery because of the higher capacity, and the charger is more basic, offering 2amp output vs. 3amp or 4amp. So expect 6 to 7 hours for a fill recharge if you go all the way down to zero. One quick warning about charging the battery while mounted to the bike, be careful with the left crank arm because it passes directly in front of the plug port on the left and could bend or snag the charging plug and cable.

The display on the Moscow Plus is upgraded, nice and large and easy to read. To begin, just hold the power button on the little control pad near the left grip. It activates the display and you get several readouts including assist level, current speed, and battery capacity. Pressing power one time will activate backlighting on the LCD display and holding the down arrow constantly will activate walk mode (which can be handy if you need to to ascend a ramp, make your way through a walk-only space, or even climb stairs). The display can show different menus if you press the set button, a nice feature to dive in a little more. I like the size and position of the display, you can even angle it forward and back to reduce reflection glare, but it is not removable. For those who plan on commuting, it might be worth strapping your helmet over the display to keep people from noticing or scratching it, and also protecting it from the sun, while parked at racks. Overall, I would still call this display panel and accompanying button pad above average, I love that it can be angled to reduce glare and feel that it looks beautiful and is well sealed against water… but to clean the bike it is recommended to use a damp cloth vs. spraying it. Don’t ever submerge the bike components or spray them hard. Also, consider storing the battery pack away from extreme heat and cold to protect the cells. The only other thing I would mention is that the display is large and center mounted, taking up a lot of valuable surface area on an already crowded handlebar, so it may be difficult to add accessories.

In conclusion, the Moscow Plus was a lot of fun, and as mentioned earlier, is using a lot of nice proven technology that has kept many happy. This is a value priced ebike, so there will be some tradeoffs to consider, so I should make mention of those now… For one, the kickstand is center mounted, so if the kickstand is down and you are reversing the bike, you will encounter pedal lock. I noticed that there is no chain ring cover or guard, so be careful when pedaling with clothing like pants or a dress. The charger is just 2amps, this means charging happens slowly, so matched with that high capacity battery, it could take quite some time. Tradeoffs aside, it is a very well put together bike with a lot of what we have come to know and love about ebikes, and at a price of just $1,899 in the US, will appeal to many customers. I want to thank NCM for the chance to check out the Moscow, and I look forward to reviewing more bikes from this new company.

As always, I welcome questions and feedback in the comment section below. Whether you own a previous version of the bike, have taken a test ride, or are brand new to the space, my goal is to provide an objective and honest resource. You can also join the Other Brands ebike forums and share your own photos, videos, and review updates to help others! Have fun out there, and ride safe :)

Pros:

  • The Moscow blends off-road geometry, suspension, and tires with urban utility because you can add fenders and a rear rack, there are also bottle cage bosses on the top as well
  • There are 24 gear combinations to explore here, and that empowers you to climb easier or hit and maintain the top assisted speed, I really appreciate the slap guard on the right chain stay and the steel derailleur guard at the rear which also protects the motor power cable (especially when the bike is being shipped)
  • The 500 watt Das-Kit motor is powerful and zippy but completely independent from the the pedal drivetrain, it’s a good choice for a bike with so many gears vs. a mid-motor, it also allows for instant throttle power regardless of which gear you’re in
  • One of the advantages of having a front derailleur is that it keeps the chain from bouncing off track, it does usually add more weight and maintenance to the bike however, and if you’re using either of the two smaller chainrings the larger 48 tooth one can snag your pant leg because there is no bash guard plate
  • Good weight distribution, the battery is positioned low and center on the frame, it seems well protected and blends in pretty well with the black accents on the fork, handlebar, seat, and chainrings
  • Great tires for cross country and street riding, the 27.5″ x 2.25″ size is lightweight and efficient, they steer quickly and Schwalbe products tend to be higher quality, there is also a 29” option as well
  • At $1,899 USD and $2,399 in CAD, it is competitively priced and will serve many customers well since it has a throttle, high capacity battery, and suspension
  • I’m glad that they chose a trigger throttle vs. twist because it makes the grips more secure and reduces accidental activation, the 12-magnet cadence sensor is also more responsive than 8 or 5 on many other products
  • The suspension fork offers compression lockout and preload adjust, this allows it to firm up for smooth riding conditions like city streets, reducing bob and energy loss as you pedal
  • You get a flick bell, locking ergonomic grips, and a pair of large sturdy platform pedals that should work well in all sorts of conditions and weather, sometimes these parts are cheaper on value priced ebikes
  • I love the high capacity 14v 16ah battery, it even has a USB port on the side to take advantage of it and use it as a power bank, perfect for traveling
  • Between the knobby tires and 80mm suspension fork, this bike feels pretty comfortable, but I might recommend a suspension seat post to make things even more cushy for your ride
  • The 180mm rotor hydraulic disc brakes are a great upgrade here, they are complimented well by a nicer derailleur, better gearing range, and more gearing options here on the Plus vs the regular Moscow
  • The Plus is actually lighter by 1.4lbs despite its larger battery, better fork, upgraded gel saddle, and nicer display

Cons:

  • Minor gripe here, but I actually prefer the integrated finger bell on the regular Moscow as opposed to this more generic bell on the Moscow Plus, this was likely chosen to save space on the handle bar since it is using a larger display
  • Some of the wires on this ebike are a bit more exposed along the base of the top tube, it looks a bit cleaner and reduces snags when they are completely internal
  • This e-bike weighs more than your average trail bike at 56.1lbs because it has a higher capacity battery and a more basic spring suspension fork vs. air, I’d definitely take the battery off when lifting and transporting it
  • No chain cover or guard means you need to be careful with your pants or dress, you don’t want it getting snagged and torn up in the chain ring system
  • Even though this is technically a mountain bike, it’s nice to see a kickstand for those urban rides, I do wish that the stand was positioned a bit further back however, to avoid pedal lock with the left crank arm
  • Another minor grips, but more and more people are commuting with hard tail mountain bikes, I like that this has provisions to add commuting options and already comes with a kickstand, but it should be noted it does not come with any lights in the front or rear
  • With a standard 2amp battery charger, it could take a while to completely fill the high-capacity battery (6 or 7 hours), there are other ebikes with 3 or even 4amp chargers but they tend to weigh more
  • The display panel isn’t removable and doesn’t swivel easily, as a result, it could get scratched more easily at racks and will take sun and rain wear over time
